New original integrated circuit chip 74HC14N DIP14 SN74HC14N

Category

Integrated Circuits (ICs)

Logic - Gates and Inverters

Mfr

Texas Instruments

Series

74HC

Package

Tube

Part Status

Active

Logic Type

Inverter

Number of Inputs

6

Features

Schmitt Trigger

Voltage - Supply

2V ~ 6V

Current - Output High, Low

5.2mA, 5.2mA

Logic Level - Low

0.3V ~ 1.2V

Logic Level - High

1.5V ~ 4.2V

Max Propagation Delay @ V, Max CL

21ns @ 6V, 50pF

Operating Temperature

-40°C ~ 85°C

Mounting Type

Through Hole

Supplier Device Package

14-PDIP

Package / Case

14-DIP (0.300"", 7.62mm)

Number of Circuits

6

Current - Quiescent (Max)

2µA

Base Product Number

74HC14
