New original imported TL494CN DIP-16 PWM control chip IC TL494

Category

Integrated Circuits (ICs)

PMIC - Voltage Regulators - DC DC Switching Controllers

Mfr

ON Semiconductor

Series

SWITCHMODE™

Package

Tube

Part Status

Obsolete

Output Type

Transistor Driver

Function

Step-Down, Step-Up/Step-Down

Output Configuration

Positive

Topology

Buck, Push-Pull

Output Phases

1

Voltage - Supply (Vcc/Vdd)

7V ~ 40V

Frequency - Switching

200kHz

Duty Cycle (Max)

48%

Synchronous Rectifier

Yes

Clock Sync

No

Serial Interfaces

-

Control Features

Dead Time Control, Frequency Control

Operating Temperature

0°C ~ 70°C (TA)

Mounting Type

Through Hole

Package / Case

16-DIP (0.300"", 7.62mm)

Supplier Device Package

16-PDIP

Number of Outputs

2

Base Product Number

TL494
